LH标准系列参数表(180T)
LH series of standard parameter table (180 t)
|
项目ITEMS |
单位 |
参数Specification |
|
系统工作压力 HYDRAULIC WORKING PRESSURE |
MPa |
14 |
|
锁模力CLAMPING FORCE |
KN |
1800 |
|
格林柱内距SPACE BETWEEN TIE BARS |
mm |
480*450 |
|
导杠直径Tie Bar Diameter |
mm |
￠85 |
|
锁模行程DIE OPENING STROKE |
mm |
380 |
|
压射力(增压)INJECTION FORCE(intensify) |
KN |
270 |
|
压射头推出距离 Plungerlaunch distance |
mm |
130 |
|
压射位置Injection position |
mm |
0 -- 140 |
|
冲头直径PLUNGER DIAMETER |
mm |
￠50----￠70 |
|
射料行程INJECTION STROKE |
mm |
350 |
|
铸造压力（增压） Casting pressure (intensify) |
MPa |
112/78/57 |
|
压射室法兰凸出定板高度 Casting Fiange Protrusion |
mm |
10 |
|
压射室法兰直径 Casting Fiange Diameter |
mm |
110 |
|
最大铸造面积(40Mpa)MAX CASTING AREA UNDER 40Mpa |
CM2 |
450 |
|
射料量(铝)lnjection Weight(Al) |
Kg |
2.4 |
|
模具厚度（最小—最大）Die Height(Min--Max) |
mm |
200～550 |
|
顶出力EJECTOR FORCE |
KN |
110 |
|
顶出行程EJECTOR STROKE |
mm |
80 |
|
电机功率Motor Capacity |
Kw |
15 |
|
外型尺寸(长*宽*高)Machine Dimensions (L*W*H) |
m |
5.22*1.4*2.35 |
|
机器吊装参考重量重量Referential Machine Weight For Uplifting |
T |
6.7 |
|
油箱容量Oil Tank Capacity |
L |
600 |
我们有权做任何技术改进而不另行通知
WE reserve the right to make any technical improvement without further notice
隆华压铸机主要性能及特点;
Primary performance and features of Longhua Die Casting machines
1,双比例控制（压力，流量电动调节，具备多级压力和速度控制以及低压合模保护功能）。
- Double proportional control (electric regulation of pressure and flow, with a multi-level pressure and speed control as well as low pressure die close protection functions).
2，双回路设计（压射和增压独立设计，互不影响，零故障）。
- Dual circuit design (air injection and pressure building are separately designed without mutual interference and fault occurrence).
3，四级(多段)压射系统：
3, four-stage (multi-stage) injection system:
A,最高速度>8M/s（2000T以上6M/s），可有效控制填充时间及压铸件成型效果，独有刹车及匀加速压射功能，有效防止毛边，压射工艺更灵活.
- maximum speed> 8M/s (6M / s for those more than 2000T), which can effectively control the filling time and casting formation, in addition to unique braking and uniform acceleration injection function that can effectively prevent flash and allow more flexible injection process.
B,最低速度0.1—0.7M/s，可进行精确控制，避免空气进入引起藏气问题。
- Minimum speed 0.1-0.7M/s, which can be precisely controlled to prevent air invasion from causing air trap.
C,增压建压时间≤15 M/s，可以按照工艺要求，改变增压速度，对压铸件加强密度而不会引起产品变
