X、Y、Z轴工作行程：Work Strokes of X、Y、Z Axles 800x1200x400mm
X、Y、Z轴定位精度
Positioning Accuracy of X、Y、Z Axles ±0.01/300mm
X、Y、Z轴重复定位精度
Repeat Positioning Accuracy of X、Y、Z Axles±0.01mm
工作台平面度
Evenness of Worktable ±0.02/300mm
X、Y垂直度
Verticality of Worktable 0.015/300mm
Z向空间高度
Spatial Height in Z Direction 450mm
主轴功率
Power of Spindle 7.5KW
主轴转速
Speed of Spindle 3500-12000rpm
驱动系统
Driving System伺服Servo
工作电压
Work Voltage三相380V
Three-Phase 380V
机床重量
Weight Machine Tool 4200Kg
机床外形尺寸
Outline Sizes Machine Tool3160×2050×2900
